Smart Mirror - MC01 Series
Don't see the options you're looking for? Request a custom quote
Pairs well with
Smart Mirror - MC01 Series
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
Your personal assistant
Simply Fascinating
Everything You Need
HOMOGENOUS ILLUMINATION
Task Lighting
Due to the most advanced ad notam lighting technology, every ad notam product becomes a real “highlight” and raise additional emotions. Our lighting technology meets the highest economical and functional standards. The design of our lighting ensures homogeneous illumination nearly up to the edge of the mirror without any shadow gaps.
The ad notam lighting technology concentrates on the essentials: the perfect utilization of light for the human in front of the mirror. Only this can guarantee a 100% authentic mirror image, in order that surprises remain in the bathroom.
Now even smarter
Smart Mirror is not just an intelligent mirror.
Smart Mirror is a mirror that has more than it takes. Indeed, as much as you want to have.
Equip your Smart Mirror with the apps of your choice and make that start to your day even better.
Most popular widgets
Radio
Listen to your favourite radio station via the integrated web radio. And your family can too. You can set up up to four user profiles. There is something there for everybody.
Youtube
Simply logon with your YouTube account and watch films, listen to music and stream the very latest videos from your favourite YouTubers.
RSS Feed
What's in the papers? Is there any new info in your friends' blogs? RSS feeds will keep you constantly updated on what's happening outside your bathroom.
Sound without any visible source
Smart Mirror plays the radio station you love via an integrated web radio. Four user profiles are available to you that you can personalize.
Control your smartphone via Bluetooth and listen to the playlist of your choice.
Whatever you do – music is in the air with Smart Mirror with invisible loudspeakers.
Tech Specs
Mirror
Thickness: 6 mm
Surface: Float
Tint: Silver
Reflection: 60 % +/- 5
Display area, when switched off: Invisible
Display
Screen Size: 7.0'' Horizontal (178 mm)
Visible Image Area: W 155 H 87 mm (7.0'' diagonale)
Physical Resolution: 1024 x 600
Picture Format: 16:9
Screen Size: 7.0'' Vertical (178 mm)
Visible Image Area: W 87 H 155 mm (7.0'' diagonale)
Physical Resolution: 600 x 1024
Picture Format: 9:16
Viewing Angle: Horizontal: Typical (Total) 178° Vertical: Typical (Total) 178°
Brightness: max. 400cd/m²
Operating System: Android
RAM: DDR3 :1 GB
HDD: 8 GB Flash
Connectivity
Wifi: 802.11b/g/n, 2.4 GHz single-band radio
Bluetooth Audio: 4.0 | Range: Typical: 10m | Power: Max.: 15.5W 12VDC / 1.29A
Sound
Type: Invisible surface speaker, Stereo
Rated power: 30 W, max. power 60 W
Impedance: 8 Ohm
Sensitivity: 85 dB
Frequency Response: 60 - 20000 Hz
Lighting
Type: LED, direct – one layer 120 LED/m
Luminance: 145 Lux @ 80 cm (diffused)
Color: 2700 K – 6000 K, changeable (progressive)
Viewing Angle: 120°
Dimmer: yes, 4 steps
Power: Voltage: DC 12V / Consumption: 9.6 W per running meter of LED
Sensors: Turn lighting on/off, dimming, color change and pairing of BT Remote Control
FAQs
Please read our FAQs page to find out more.
How do I clean the product?
To avoid damages please ensure the observance of the following instructions:
• Use mild, fast-drying household spray glass cleaning solutions with ammonia and water. Ammonia concentration not to exceed 1.5% of weight.
• Use a lint-free paper cloth that is non abrasive or a soft cotton cloth without seams, buttons, plastic or metal parts.
• Pre-moisten glass surface with water or cleaning solution to loosen dried dirt and debris before attempting to wipe it away - never scrape with a metal blade or tool
• Never use abrasive household detergents as cleaning agents.
• Never attempt to remove debris /dirt from the glass by using a scraper or razor blade.
• Never trap abrasive particles between the cloth and the glass surface while wiping away the cleaning solution.
Is it easy to install the product?
For ad notam it is very important that our products can be installed easily and safely. For this reason, in contrast to other industry providers, we always supply a mounting template for surface-mounted installations. This ensures that all wall brackets are in the correct position and the installation is completed within a short time.
Does the product come with integrated loudspeakers?
Yes, the product is equipped with invisible surface loudspeakers.
Is the TV screen completely invisible when switched off?
Yes, our mirror delivers the highest standard of picture quality when turned on, while when turned off, the screen area completely disappears, leaving your mirror as an elegant fixture in your environment.
Doesn`t the humidity in bathrooms affect the product?
No, the product can be safely installed in bathrooms zone 3 (IPX2 rating). If you wish to install our products outside of zone 3, you have to contact us for guidance upfront.
